OPTIONAL PARTS
14
Deodorizing filter (Gray sponge type)
Air cleanig filter (White bellows type)
14-1. AIR CLEANING FILTER
● AIR CLEANING FILTER removes fine dust of 0.01 micron from air by means of static electricity.
● Normal life of AIR CLEANING FILTER is 4 months. However, when it becomes dirty, replace it as soon as possible.
● Clogged AIR CLEANING FILTER may reduce the air conditioner capacity or cause frost on the air outlet.
● DO NOT reuse AIR CLEANING FILTER even if it is washed.
● DO NOT remove or attach AIR CLEANING FILTER during unit operation.
14-2. DEODORIZING FILTER
● DEODORIZING FILTER removes ammonia and hydrogen sulphide emitted from tobacco, and odor of pets.
● Clean DEODORIZING FILTER every two weeks. If the filter is particularly dirty, clean the filter more often.
● For cleaning, soak the filter in warm water for a while, and then wash and rinse it. Dry the filter in the shade thoroughly.
● When the filter color is still dark even after cleaning, replace the filter with a new one.
Replace the filter at least once a year.
● DEODORIZING FILTER and AIR CLEANING FILTER can be attached on either side.
Model
Part No.
MAC-1100FT
MAC-1700FT
MSH-18RV-
E1
MSH-24RV-
E1
MSH-30RV-
E1
Model
Part No.
MAC-1600DF
MAC-2200DF
MSH-18RV-
E1
MSH-24RV-
E1
MSH-30RV-
E1
MUH-18RV -
MUH-18RV -
MUH-24RV -
MUH-30RV -
13-12. ACCESSORY
E1
E1
E2
E1
Symbol
in Wiring
Diagram
Q'ty/unit
MUH-18RV-
Remarks
Part No.
NO.
Part Name
E1
MUH-24RV-
E1
MUH-30RV-
E1
MUH-18RV-
E2
E02 444 704
E02 329 704
E02 444 705
E02 444 706
1
2
DRAIN SOCKET
DRAIN SOCKET
DRAIN CAP
DRAIN CAP
1
2
1
1
6
1
6
[33
[16
1
2
1
1
2
New publication, effective Jan. 2002
Specifications subject to change without notice.
CC
Copyright 2001 MITSUBISHI ELECTRIC ENGINEERING CO.,LTD
Distributed in Jan. 2002. No.OB272 REVISED EDITION-A 272
Distributed in Feb. 2001. No.OB272 548
Made in Japan
HEAD OFFICE: MITSUBISHI DENKI BLDG.,2-2-3, MARUNOUCHI, CHIYODA-KU, TOKYO100-8310, JAPAN
OB272-3.qxp 02.1.26 1:24 PM Page 88
