SPECIFICATION
3
Outdoor model
Function
Power supply
Capacity
Dehumidification
Air flow(High/Low )
Starting current
Compressor motor current
Fan motor current
Model
Output
Winding
resistance(at20:)
Model
Winding
resistance(at20:)
Dimensions WOHOD
Weight
Sound level(High)
Fan speed(High/Low )
Fan speed regulator
Refrigerant filling
capacity(R410A)
Refrigerating oil (Model)
Thermistor RT61(at0:)
Thermistor RT62(at25:)
Thermistor RT63(at0:)
kW
R/h
K /h
A
A
A
W
"
"
mm
kg
dB
rpm
kg
cc
k"
k"
k"
MUH-A30WV -
E1
Single phase
230V, 50Hz
90
0.57
NN37VAAHT
2,500
C-R 0.64
C-S 1.63
RA6V75-AB
WHT-BLK 62.8 BLK-YLW 55.9
YLW-RED 26.0
840o850o330
77
55
805/435
2
2.30
1,300 (NEO 22)
33.18
231.44
33.18
Cooling
8.5
4.6
2,940/1,470
13.85
2.52-2.40
Heating
9.4
—
2,940/1,470
14.62
2.73-2.70
Electrical data
Compressor
Fan motor
Special remarks
Coefficient of performance(C.O.P)
Capacity
www
w
w
Outdoor model
Function
Power supply
Capacity
Dehumidification
Air flow(High)
Starting current
Compressor motor current
Fan motor current
Model
Output
Winding
resistance(at20:)
Model
Winding
resistance(at20:)
Dimensions WOHOD
Weight
Sound level(High)
Fan speed(High)
Fan speed regulator
Refrigerant filling
capacity(R410A)
Refrigerating oil (Model)
Thermistor RT61(at0:)
kW
r/h
K /h
A
A
A
W
"
"
mm
kg
dB
rpm
kg
cc
k"
MUH-A18WV -
E1
Single phase
230V, 50Hz
2,196
37
0.39
RN196VHSHT
1,300
C-R 1.80
C-S 3.00
RA6V50-OG
WHT-BLK 116
BLK-RED 111
850o605o290
47
52
828
1
1.75
520 (NEO22)
33.18
Cooling
5.0
2.5
7.54
2.81
Heating
5.2
—
6.84
3.23
MUH-A24WV -
E1
Single phase
230V, 50Hz
2,760
74
0.58
NN29VBAHT
1,900
C-R 0.80
C-S 1.64
RA6V85-AB
WHT-BLK 63 BLK-YLW 30
YLW-RED 63
840o850o330
74
53
730
1
2.15
1,200 (NEO22)
33.18
Cooling
6.3
3.2
9.81
2.61
Heating
7.2
—
10.12
2.90
Electrical data
Compressor
Fan motor
Special remarks
Coefficient of performance(C.O.P)
Capacity
NOTE: Test conditions are based on JIS C 9612.
Cooling : Indoor DB27°C WB19°C Heating : Indoor DB20°C WB 15.5°C
Outdoor DB35°C WB(24°C) Outdoor DB 7°C WB 6°C
Indoor-Outdoor piping length 5m
w Reference value
