Mitsubishi PE-10MYC User Manual

- 91 -
3. Installation of the unit.
Indoor unit
Please carry the packed until parallelly to installed place.
Please install the unit before construction of the ceiling -lined.
U washer
100 over
30
100 over
30
Nut
Nut
Washer
PEH-5 PE(H)- 7, 8, 10
PE(H)- 15, 20
100 over
Nut (M10)
Washer
30
Washer
Nut (M10)
Nut (M10)
Nut (M10)
Ceiling
Fix unit tightly with bolts as shown below so that unit will be securely fixed
in place use concrete or angle foundation of unit.
At the time of bottom piping of refrigerant pipe, build a 100mm or higher
foundation so that piping will go through bottom of unit.
Concrete foundation
Installation pitch
Outdoor unit
Anchor bolt (local arrangement)
PUH-5 PU(H)-7, 8, 10
PU(H)-15, 20
M8
M10
