Mitsubishi PEAD-A24AA4 User Manual

33
PEAD-A24AA4
PEAD-A30AA4
PEAD-A36AA4
PEAD-A42AA4
1. Control box
1. Removing the control box cover
(1) Remove the two fixing screws on the cover (A)
to remove it.
2. Thermistor (Intake air)
1. Remove the control box cover according to the
procedure in section [1].
(1) Pull out the thermistor holder (B) and thermis-
tor (C) on the control box.
(A)
Fig. 1
Fig. 2
(B),(C)
Fig. 3
DISASSEMBLY PROCEDURE
11
Exercise caution when removing heavy parts.
