Mitsubishi PUG42AYB User Manual

036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 7
PK18+PUG18 (Indoor Air = 710 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 19,283 12.38 1,558 11,535 14,927 18,319 21,711 25,103 72 198
65 20,058 12.76 1,572 10,084 13,476 16,868 20,260 23,652 74 202
67 20,833 13.14 1,585 8,632 12,024 15,416 18,808 22,200 76 206
69 21,530 13.54 1,591 6,925 10,317 13,709 17,101 20,493 82 208
71 22,226 13.93 1,596 5,218 8,610 12,002 15,394 18,786 87 210
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 18,401 11.02 1,670 11,047 14,439 17,831 21,223 24,615 76 231
65 19,259 11.42 1,687 9,720 13,112 16,504 19,896 23,288 78 234
67 20,117 11.81 1,704 8,393 11,785 15,177 18,569 21,961 81 238
69 20,812 12.15 1,712 6,612 10,004 13,396 16,788 20,180 85 239
71 21,508 12.50 1,721 4,830 8,222 11,614 15,006 18,398 89 241
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 17,518 9.83 1,782 10,559 13,951 17,343 20,735 24,127 80 263
65 18,459 10.24 1,802 9,356 12,748 16,140 19,532 22,924 83 266
67 19,400 10.65 1,822 8,154 11,546 14,938 18,330 21,722 85 269
69 20,095 10.96 1,834 6,298 9,690 13,082 16,474 19,866 88 271
71 20,789 11.26 1,846 4,442 7,834 11,226 14,618 18,010 90 272
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 16,284 8.55 1,905 9,261 12,653 16,045 19,437 22,829 85 301
65 17,000 8.86 1,919 8,420 11,812 15,204 18,596 21,988 87 303
67 17,716 9.16 1,933 7,579 10,971 14,363 17,755 21,147 89 306
69 18,567 9.50 1,955 5,730 9,122 12,514 15,906 19,298 91 308
71 19,417 9.83 1,976 3,882 7,274 10,666 14,058 17,450 94 311
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 15,049 7.42 2,028 7,964 11,356 14,748 18,140 21,532 90 339
65 15,541 7.63 2,037 7,484 10,876 14,268 17,660 21,052 91 341
67 16,032 7.84 2,045 7,004 10,396 13,788 17,180 20,572 92 342
69 17,039 8.21 2,075 5,162 8,554 11,946 15,338 18,730 95 346
71 18,045 8.57 2,106 3,321 6,713 10,105 13,497 16,889 98 350
PERFORMANCE DATA - OPERATING PRESSURES
4
