4.1.3 Notes on installing the base unit
Take ease of operation, ease of maintenance, and environmental durability into
consideration when you are installing the programmable controller on the panel.
(1) Mounting dimension
Mounting dimensions of each base unit are as follows:
CPU 0 1 2 3 4 5 6 7
POWER
MITSUBISHI E LECTRIC CORPORATIO N BD626E680 G52
MADE IN JAPAN E.S.D. A1S38B
Ws
W
Hs
H
A1S32B A1S33B A1S35B
A1S38B
A1S38HB
A1S38HBEU
A1S52B
(S1)
A1S55B
(S1)
A1S58B
(S1)
A1S65B
(S1)
A1S68B
(S1)
W
220
(8.66)
255
(10.04)
325
(12.80)
430
(16.93)
155
(6.10)
260
(10.24)
365
(14.37)
315
(12.40)
420
(16.54)
Ws
200
(7.87)
235
(9.25)
305
(12.01)
410
(16.14)
135
(5.31)
240
(9.45)
345
(13.58)
295
(11.61)
400
(15.75)
H 130 (5.12)
Hs 110 (4.33)
Dimensions: mm (inch)
