4.3 Wiring
4.3.1 Power supply module specifications
(1) Table 4.1 shows the specifications of the power supply modules.
Table 4.1 Power supply module specifications
Specifications
Item
A1S61PN A1S62PN A1S63P
Base unit position Power supply module slot
Rated input voltage
100 to 240 V AC (+10 %/-15 %)
(85 to 264 V AC)
24 V DC
(+30 %/-35 %)
(15.6 to 31.2 V DC)
Rated input frequency 50/60 Hz ± 5 % ⎯⎯
Input voltage distortion factor Within 5 % (Refer to Section 4.4) ⎯⎯
Max. input apparent power 105 V A 41 W
Inrush current 20 A 8 ms or lower *4 81 A 1 ms or lower
5 V DC 5 A 3 A 5 A Rated output
current
24 V DC ± 10 % ⎯⎯ 0.6 A ⎯⎯
5 V DC 5.5 A or higher 3.3 A or higher 5.5 A or higher Overcurrent
protection *1
24 V DC ⎯⎯ 0.66 A or higher ⎯⎯
5 V DC 5.5 to 6.5 V Overvoltage
protection *2
24 V DC ⎯⎯
Efficiency 65 % or higher
Allowable momentary power
failure time *3
20 ms or higher 1 ms or lower
Between primary
and 5 V DC
500 V AC
Dielectric
withstand
voltage
Between primary
and 24 V DC
AC across input/LG and output/FG
2830 V AC rms/3 cycle
(2000 m (6562 ft.))
⎯⎯
Insulation resistor
AC across input/LG and output/FG 10 M
or higher,
measures with a 500 V DC insulation resistance tester
Noise durability
(1) Noise voltage 1500 Vp-p, Noise
width 1
s, Noise frequency 25 to 60
Hz (noise simulator condition)
(2) Noise voltage IEC801-4, 2 kV
Noise voltage 500 Vp-p,
Noise width 1 s, Noise
frequency 25 to 60 Hz
(noise simulator condition)
Power indication Power LED indication (light at the time of output of 5 V DC)
Terminal screw size M3.5 × 7
Applicable wire size 0.75 to 2 mm
2
(AWG 18 to 14)
Applicable solderless terminal
RAV 1.25 to 3.5,
RAV 2 to 3.5
Applicable tightening torque 59 to 88 N⋅cm
External dimension 130 × 55 × 93.6 (5.12 × 2.17 × 3.69) mm (inch)
Weight 0.60 kg 0.50 kg
