7 - 1 7 - 1
MELSEC-Q
7 CONNECTORS
7. CONNECTORS
The 40-pin connectors and 37-pin D-sub connectors used with the input and output
modules are to be user-prepared.
The following tables list the connector types and applicable models, and introduce
crimp-contact and pressure-displacement tools.
(1) 40-pin connectors
(a) 40-pin connectors
Type Model name Applicable wire size Applicable model
Soldering type connector
(straight out type)
A6CON1
*1
0.088 to 0.3mm
2
(28 to 22 AWG) (stranded wire)
QX41, QX41-S1,
QX41-S2, QX42,
QX42-S1, QX71, QX72,
QX82, QY41H, QY41P,
QY42P, QY71, QY82P,
QH42P, QX41Y41P
Crimp-contact type connector
(straight out type)
A6CON2
0.088mm
2
to 0.24mm
2
(28 to 24 AWG)
(stranded wire)
Pressure-displacement type connector
(straight out type)
A6CON3
28 AWG (stranded wire)
30 AWG (single wire)
Flat cable 1.27mm pitch
Soldering type connector
(both for straight out and 45-degree
types)
A6CON4
*1
0.088 to 0.3mm
2
(28 to 22 AWG)
(stranded wire)
*1: Use cables with outside diameter of 1.3mm or shorter to connect 40 cables
to the connector. In addition, consider the amount of current to be used and
select appropriate cables.
(b) 40-pin connector crimp-contact and pressure-displacement
tools
Type Model name Contact
Crimp-contact tool FCN-363T-T005/H
FUJITSU COMPONENT
LIMITED
Pressure-displacement tool
FCN-367T-T012/H
(locator plate)
FCN-707T-T001/H
(cable cutter)
FCN-707T-T101/H
(hand press)
7
