8 - 1 8 - 1
MELSEC-Q
8 SPECIFICATIONS OF CONNECTOR/TERMINAL BLOCK CONVERTER
MODULES
8. SPECIFICATIONS OF CONNECTOR/TERMINAL BLOCK CONVERTER
MODULES
8.1 Specifications of Connector/Terminal Block Converter Modules
This chapter explains the specifications of connector/terminal block converter modules.
(1) Connector/terminal block converter module
Type Details Weight
Applicable
wire size
Applicable
crimping
terminal
Applicable Models
A6TBXY36
For positive common type input
modules and sink type output
modules (standard type)
0.4kg
0.75
to
2mm
2
1.25-3.5(JIS)
1.25-YS3A
V1.25-M3
V1.25-YS3A
2-3.5(JIS)
2-YS3A
V2-S3
V2-YS3A
Q series QX41, QX41-S1, QX41-S2, QX42,
QX42-S1, QY41H, QY41P, QY42P,
QY82P, QH42P, QX41Y41P
AnS series A1SX41, A1SX41-S1, A1SX41-S2,
A1SX42, A1SX42-S1, A1SX42-S2,
A1SX82-S1, A1SY41, A1SY41P,
A1SY42, A1SY42P, A1SY82, A1SH42,
A1SH42P, A1SH42-S1, A1SH42P-S1
A series AX42, AX42-S1, AY42, AY42-S1,
AY42-S3, AY42-S4, AH42
CC-Link AJ65SBTCF1-32D, AJ65SBTCF1-32T,
AJ65BTC1-32D, AJ65BTC1-32T
MELSECNET-MINI AJ35TC1-32D, AJ35TC1-32T
A6TBXY54
For positive common type input
modules and sink type output
modules (2-wire type)
0.5kg
A6TBX70
For positive common type input
modules
(3-wire type)
0.6kg
Q series QX41, QX41-S1, QX41-S2, QX42,
QX42-S1, QH42P, QX41Y41P
AnS series A1SX41, A1SX41-S1, A1SX41-S2,
A1SX42, A1SX42-S1, A1SX42-S2,
A1SX82-S1, A1SH42, A1SH42P,
A1SH42-S1, A1SH42P-S1
A series AX42, AX42-S1, AH42
CC-Link AJ65SBTCF1-32D, AJ65BTC1-32D
MELSECNET-MINI AJ35TC1-32D
A6TBX36-E
For negative common type input
modules (standard type)
0.4kg
Q series QX81, QX81-S2
AnS series A1SX81, A1SX81-S2
A series AX82
A6TBX54-E
For negative common type input
modules (2-wire type)
0.5kg
A6TBX70-E
For negative common type input
modules (3-wire type)
0.6kg
A6TBY36-E
For source type output modules
(standard type)
0.4kg
Q series QY81P
AnS series A1SY81
A series AY82EP
A6TBY54-E
For source type output modules
(2-wire type)
0.5kg
8
