38
-
2.2.2 Range of usage & limitations
2.2.3 Exterior dimensions
Indoor return air temperature
(Upper, lower limits)
Refrigerant line (one way) length Max. 15m
All models
Refer to the selection chart
Power source voltage Rating ± 10%
Voltage at starting Min. 85% of rating
Frequency of ON-OFF cycle Max. 10 times/h
ON and OFF interval Max. 3 minutes
Outdoor air temperature
(Upper, lower limits)
Vertical height difference between
outdoor unit and indoor unit
Max. 5m (Outdoor unit is higher)
Max. 5m (Outdoor unit is lower)
Item
Models
(1) Indoor unit
Models SRK10CHV-4, 13CHV-4
Unit: mm
Piping hole (ø65)
( )
Piping hole (ø65)
53.5
380.6
Piping for Liquid 448.6 (ø6.35)
10 :ø9.52
13 :ø12.7
Piping for Gas
Drain hose 520 (ø16)
53.5
44.5
252.2
7.5
8.3
102.5
585
102.5
133.5450206.5
202450138
44.5
43.2
39.3
200
45
45
60
17.5
60
27
788
45
2.1
960
124
224 
3
Terminal block
Piping hole right(left)
268
790
A
VIEW A
→
