PART NAMES AND FUNCTIONS
OUTDOOR UNIT
Air inlet
Air outlet
Drain outlet
Piping
Drain hose
(back and side)
ACCESSORIES
1
Drain socket
1
SUZ-A09VR.TH
SUZ-A12VR.TH
SUZ-A09VR.TH
SUZ-A12VR.TH
OUTDOOR UNIT
Air inlet
Piping
Air outlet
(back and side)
Drain hose
Drain outlet
ACCESSORIES
1
2
Drain socket
Drain cap [33
1
2
SUZ-A18VR.TH
SUZ-A24VR.TH
SUZ-A18VR.TH
SUZ-A24VR.TH
