A-10 DAILY INSPECTION
6.5 Cleaning the Rear of the Cylinder (Hollow Chuck)
Coolant and chips flow to coolant pan at the rear of the cylinder via the through hole in the draw
pipe.
The coolant returns to the coolant tank via the drain hose.
Chips accumulate on the punched-metal sheet at the rear of the cylinder.
Remove chips from the punched-metal sheet every day. If chips are left to accumulate,
coolant will overflow and spill onto the shop floor.
Coolant will flow into the hydraulic oil tank via the cylinder drain, inhibiting proper
machine operation.
<Procedure>
1) Turn off the power.
2) Remove the cylinder cover at the left side of the machine.
3) Remove the chips that have accumulated on the punched-metal sheet at the rear of the
cylinder.
Do not touch the chips bare handed.
Remove coolant and chips that have accumulated in the cylinder at regular intervals by
detaching the rear cover of the cylinder.
CAUTION
CAUTION
NOTE
