2-2 56F8323EVM User Manual MOTOROLA
• Memory Daughter Card Expansion Connector, which allows the user to attach
additonal power and grounds[J2]
• Connector which allows the user to attach his own SCI #0 / MPIO-compatible
peripheral [J21]
• Connector which allows the user to attach his own SCI #1 / MPIO-compatible
peripheral [J17]
• Connector which allows the user to attach his own SPI #0 / MPIO-compatible
peripheral [J8]
• Connector which allows the user to attach his own SPI #1 / MPIO-compatible
peripheral [J15]
• Connector which allows the user to attach his own PWMA-compatible peripheral
[J5]
• Connector which allows the user to attach his own CAN physical layer peripheral
[J10]
• Connector which allows the user to attach his own Timer A / Encoder
#0-compatible peripheral [J7]
• Connector which allows the user to attach his own Timer C-compatible peripheral
[J9]
• Connector which allows the user to attach his own A/D port A-compatible
peripheral [J6]
• Connector which allows the user to attach his own peripheral to GPIO Port A [J16]
• Connector which allows the user to attach his own peripheral to GPIO Port B [J18]
• Connector which allows the user to attach his own peripheral to GPIO Port C [J19]
• On-board power regulation from an external +12V DC-supplied power input [P3]
• Light Emitting Diode (LED) power indicator [LED13]
• Six on-board LEDs allow real-time debugging of user programs [LED1-6]
• Six on-board Port A PWM monitoring LEDs [LED7-12]
• Internal (OCR_DIS) Core Regulator selector [JG12]
• Temperature Sense Diode-to-ANA7 selector [JG6]
• Manual RESET push-button [S1]
• Manual interrupt push-button for IRQA
[S2]
• General purpose jumper on GPIO PB3 [JG7]
• General purpose jumper on GPIO PB0 [JG8]
• Optional 4-Channel 10-bit Serial D/A, SPI for real-time user data display [U5]
