2.1 56F8323
The 56F8323EVM uses a Motorola MC56F8323FG60 part, designated as U1 on the board
and in the schematics. This part will operate at a maximum external bus speed of 60MHz.
A full description of the 56F8323, including functionality and user information, is
provided in these documents:
• 56F8323 Technical Data Sheet, (MC56F8323/D): Electrical and timing
specifications, pin descriptions, device specific peripheral information and package
descriptions (this document)
• 56F8300 Peripheral User Manual, (MC56F8300UM/AD): Detailed description of
peripherals of the 56F8300 family of devices
• DSP56800E Reference Manual, (DSP56800ERM/D): Detailed description of the
56800E family architecture, 16-bit core processor, and the instruction set
Refer to these documents for detailed information about chip functionality and operation.
They can be found on this URL:
www.motorola.com/semiconductors
