7
English
Note: All the transformers listed in Table 2 can also be used with the
HTN9000 charger.
OPERATING INSTRUCTIONS
Single-unit chargers will charge only the Motorola
authorized batteries listed in Table 1 on page 5 Other
batteries may not charge.
The battery charger’s pocket will accommodate
either a radio with a battery attached or a battery
alone. Prior to charging a battery with radio, turn
the radio off. To charge a battery, use the following
procedure: (Refer to Figure 1, page 8)
1. Plug the round end of the transformer cord into the
socket on the back of the charger.
PMLN5196 90–264Vac (Euro plug) 2571886T01
PMLN5197 90–264Vac (U.S. plug) 2571886T01
PMLN5205 90–264Vac (Aus/NZ plug) 2571886T01
WPLN4282 90–264Vac (Brazil plug) 2571886T01
Table 2. Kits/Power Sources/Transformers
Kit Number Power Source
Transformer
(part) Number
6881088C11_na.book Page 7 Thursday, April 7, 2016 1:39 PM
