Overview of Your Baby Unit
1
2
3
7
8
4
5
6
Important guidelines for installing your baby monitor
• To use your baby unit and parent unit together, you must be able to establish
a radio link between them, and the range will be affected by environmental
conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic
door or reinforced concrete, between the baby unit and parent unit may
block the radio signal.
• The signal strength may also be reduced by other solid structures, like walls,
or by radio or electrical equipment, such as TVs, computers, cordless or
mobile phones, fluorescent lights or dimmer switches.
• If the signal is poor, try moving the parent unit and/or the baby unit to
different positions in the rooms.
1. Camera lens
2. Infrared lights
4 x infra-red LEDs for night vision
illumination.
3. Power/Link indicator
On steadily when the baby unit is
powered on and currently linked to
parent unit.
Flashes when the baby unit is not
linked to a parent unit; or the pairing
process is in progress; or the parent
unit is not viewing this baby unit.
4. Microphone
5. Control key panel
PAIR
Press and hold to pair with the parent
unit.
Power ON/OFF button
P
Press and hold to turn on or off.
6. Stand
Tilt to adjust the camera angle.
7. Power jack
8. Base
