Motorola MG8702 Quick Start Guide

13
Front Panel Lights
During power up, the lights will blink for about a minute.
LIGHT
COLOR
DESCRIPTION
Power
Green
ON: MG8702 power on
OFF: MG8702 power off
Downstream
Green or
Blue
Green Blinking:
Scanning for DS channel
Green ON:
Connected on 1 channel
Blue Blinking:
Negotiating bonded
channel(s)
†
Blue ON:
Bonded with 2 or more
channels
Upstream
Green or
Blue
Green Blinking:
Ranging in progress
Green ON:
Connected on 1 channel
Blue Blinking:
Negotiating bonded
channel(s)
†
Blue ON:
Bonded with 2 or more
channels
OFF:
Upstream not connected
Online
Green or
Blue
Blinking:
Trying to go online
Green
:
Blue:
Online
with DOCSIS 3.0
Online with DOCSIS 3.1
OFF:
Offline
2.4 GHz
WLAN
Green
Blinking:
Data is flowing
ON:
WiFi is enabled
OFF:
WiFi is not enabled
5 GHz WLAN
Green
Blinking:
Data is flowing
ON:
WiFi is enabled
OFF:
WiFi is not enabled
WPS
Green
ON
WPS is in discovery mode
OFF
:
Turns off after configuration
is successful
USB
Green
ON:
Light will remain solid
when USB port is in use
Rear Panel
Ethernet LAN
port(s)
Green or
Amber
Blinking:
Ethernet data is flowing
Green:
Connected at 1 Gbps
Amber:
Connected at 10 or 100 Mbps
OFF:
No connection
† If a blue light blinks continuously, this indicates partial service, which means
that at least one designated channel has not completed bonding. You should
still get high Internet speeds, but your service provider may want to know so
they can adjust their network.
