Getting to know your baby monitor
2. Getting to know your baby monitor
Overview of your baby (camera) unit
2
3
5
7
6
8
9
1
4
10
1. High intensity infrared LEDs behind the black lens
Picks up clear images in the dark when the built-in photo sensor detects a low
level of ambient light, the screen on the parent unit will turn black and white.
The night vision icon will be displayed at the top of the LCD screen.
2. Camera
3. Desk stand
4. Microphone
Picks up the sound from the baby.
Note: Make sure you remove any cover or protective tape on it.
5. Speaker
6. Antenna
7. Power jack
8. Power / Linking LED indicator
Lights up in blue when the parent unit is powered on and linked to the baby
(camera) unit.
9. Pair button
Press and hold to pair with the parent unit.
10. Temperature sensor (Night vision mode)
The temperature reading from the temperature sensor at the back of the baby
unit will be displayed at the top of the LCD screen. The reading will turn RED
if the temperature goes above 29°C / 84°F or below 14°C / 57°F. The reading
will change to HH °C / °F if the temperature goes above 36°C / 97°F. The
reading will change to LL °C / °F if the temperature goes below 1°C / 34°F.
