EN © mPTech 2022. All rights reserved. myPhone Halo 2
23
directly after turning the phone on you will see the code request, (in form
of “****”) type the code and press <Menu button> (3).
Inserting a SIM card, memory card, and the battery
If the phone is switched on - switch it off. Remove the back cover -pry it by
the gap in the cover (18). Insert the SIM card with its gold contacts facing
down, the way in which the slot is embossed.
Insert the memory card - to open the flip of the card reader slide it
delicately down. Insert the microSD memory card with its gold contacts
facing down, the way in which the slot is embossed.
close the flip by sliding it delicately up. Insert the battery so that its gold
contacts touch the connectors in the phone bay. Put on and gently press
down the cover until you hear the click of the latches. Make sure that the
flap is properly fitted and secured. To remove the battery, gently remove
the back flap and carefully remove the battery.
Charging the phone
Charging without a cradle charger
Connect the microUSB charger to the charger connector on your phone,
then connect the charger plug into the power grid.
*Attention: Improper connection of the charger can cause serious damage
to the phone. Damages caused by an improper use of the phone are not
covered by the warranty.
The icon (or similar) will appear during charging and when the battery
is fully charged. When charging is complete unplug the charger from the
power outlet. Unplug the cable from the socket on the phone.
Charging with a cradle charger
Connect the microUSB charger to the connector in the cradle charger, then
connect the charger plug into the power grid. Place the phone in the
