MSI 865PE/G Neo2-P MS-6728 User Manual

A-15
Using 4- or 6-Channel Audio Function
1 * Line Out (Rear channels)
2 Line Out (Front channels)
3 * Line Out (Center and Subwoofer channel)
4 SPDIF Coaxial jack
* Both Line In and MIC
function are converted to Line
Out function when 6-Channel
Mode for 6-Speaker Output is
selected.
 6-Channel Mode for 6-Speaker Output
Refer to the following diagram and caption for the function of each
jack on the back panel when 6-Channel Mode is selected.
MSI Reminds You...
If the audio signals coming from the Center and Subwoofer
speaker are swapped when you play video or music on the
computer, a converter may be required to exchange center and
subwoofer audio signals. The converter can be purchased from
a speaker store.
Back Panel
3
1
24
