SB Phase LEDs
These LEDs ndcate the current SB power phase mode. Follow the nstructons below
to read.
Lghts O󰘯
SB s n 1 phase power mode. SB s n 2 phase power mode.
DDR Phase LEDs
These LEDs ndcate the current DDR power phase mode. Follow the nstructons below
to read.
Lghts O󰘯
DDR s n 1 phase power mode. DDR s n 2 phase power mode.
Power LED
Lghts blue when you press the Power button and t s functonal.
Reset LED
Lghts blue when you press the Reset button and t s functonal.
GreenPower LED
Lghts blue when you press the GreenPower button and t s functonal.
OC Dal LED
Lghts when you press the OC Dal button and t s functonal.
