MSI B450M GAMING PLUS User Manual

3
Safety Information Specifications
Specifications
CPU
Supports AMD
®
Ryzen 1st and 2nd Generation/ Ryzen™
with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega
Graphics Processors for Socket AM4
Chipset AMD
®
B450 chipset
Memory
y 2x DDR4 memory slots, support up to 32GB*
 Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
 Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz
(by A-XMP OC MODE)
y Dual channel memory architecture
y Supports ECC UDIMM memory (non-ECC mode)
y Support non-ECC UDIMM memory
* Please refer www.msi.com for more information on
compatible memory.
Expansion Slots
y 1x PCIe 3.0 x16 slot (PCI_E1)
 Supports x16 speed with AMD
®
Ryzen™ 1st and 2nd
Generation processors
 Supports x8 speed with AMD
®
Ryzen™ with Radeon
Vega Graphics processors
 Supports x4 speed with AMD
®
Athlon™ with Radeon™
Vega Graphics Processors
y 2x PCIe 2.0 x1 slots
Onboard
Graphics
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz*
y 1x HDMI™ 1.4 port, supports a maximum resolution of
4096x2160 @30Hz, 2560x1600 @60Hz*
* Only support when using AMD
®
Ryzen™ with Radeon™ Vega
Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
* Maximum shared memory of 2048 MB
Storage
AMD
®
CPU
y 1 x M.2 slot (Key M)
 Supports PCIe 3.0 x4 (AMD
®
Ryzen 1st and 2nd
Generation/ Ryzen™ with Radeon™ Vega Graphics) or
PCIe 3.0 x2 (AMD
®
Athlon™ with Radeon™ Vega Graphics)
and SATA 6Gb/s 2242/ 2260 /2280/ 22110 storage devices
AMD
®
B450 Chipset
y 4x SATA 6Gb/s ports
Audio
y Realtek
®
ALC887 Codec
y 7.1-Channel High Definition Audio
LAN 1x Realtek
®
8111H Gigabit LAN controller
Continued on next page

MSI B450M GAMING PLUS Specifications

General

Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	AMD B450
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of mounting holes	6
Motherboard chipset family	AMD
Windows operating systems supported	Windows 10, Windows 7
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466 MHz
Processor socket	Socket AM4
Compatible processor series	AMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Maximum graphics card memory	2048 MB
Number of SATA II connectors	0
Number of SATA III connectors	4
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
Cables included	SATA
BIOS type	UEFI

Weight and Dimensions

Depth	210 mm
Width	244 mm
