Gettng Started
Memory
These DIMM slots are used for nstallng memory modules. For more nformaton on
compatble components, please vst http://www.ms.com/servce/test-report
DDR3
240-pn, 1.5V
48x2=96 pn 72x2=144 pn
Dual-Channel mode Populaton Rule
In Dual-Channel mode, the memory modules can transmt and receve data wth two
data bus channels smultaneously. Enablng Dual-Channel mode can enhance system
performance. The followng llustratons explan the populaton rules for Dual-Channel
mode.
1
DIMM1
DIMM2
DIMM3
DIMM4
2
DIMM1
DIMM2
DIMM3
DIMM4
Important
DDR3 memory modules are not nterchangeable wth DDR2, and the DDR3 standard
s not backward compatble. Always nstall DDR3 memory modules n DDR3 DIMM
slots.
To ensure system stablty, memory modules must be of the same type and densty
n Dual-Channel mode.
Due to chpset resource usage, the system wll only detect up to 31+ GB of memory
(not full 32 GB) when all DIMM slots have 8GB memory modules nstalled.
•
•
•
Installed
Empty

MSI B75A-G43 seres Specifications

General

Chipset	Intel B75
Socket	LGA 1155
Form Factor	ATX
Max Memory	32GB
Memory Standard	DDR3 1066/1333/1600
PCI Express x1	2
PCI Slots	3
SATA 3Gb/s	5
SATA 6Gb/s	1
Audio	Realtek ALC892
USB 3.0	2 x Rear, 2 x Header
LAN	Realtek 8111E
Video Outputs	VGA, DVI, HDMI
Memory Slots	4 x DIMM
