MSI B75A-G43 seres User Manual

2-4
BIOS Setup
Operaton
CLICK BIOS II allows you to control BIOS settngs wth the mouse and the keyboard.
The followng table lsts and descrbes the hot keys and the mouse operatons.
Hot key Mouse Descrpton
<↑↓→← >
Move the cursor
Select Item
<Enter>
Clck/ Double-
clck the left
button
Select Icon/ Feld
<Esc>
Clck the rght
button
Jump to the Ext menu or return to the prevous from
a submenu
<+> Increase the numerc value or make changes
<-> Decrease the numerc value or make changes
<F1> General Help
<F4> CPU Spec󰘰catons
<F5> Enter Memory-Z
<F6> Load optmzed defaults
<F10> Save Change and Reset
<F12> Save a screenshot to a FAT/FAT32 USB drve
Sub-Menu
If you 󰘰nd a pont symbol to the left of certan 󰘰elds,
that means a sub-menu can be launched for ad-
dtonal optons. You can use the arrow keys or
mouse to hghlght the 󰘰eld and press <Enter> or
double-clck the left mouse button to enter the sub-
menu. If you want to return to the prevous menu, just press <Esc> or clck the rght
mouse button.
General Help
The General Help screen lsts the approprate keys to use for navgaton. You can call
up ths screen from any menu by smply pressng <F1>. Press <Esc> to ext the Help
screen.

MSI B75A-G43 seres Specifications

General

Chipset	Intel B75
Socket	LGA 1155
Form Factor	ATX
Max Memory	32GB
Memory Standard	DDR3 1066/1333/1600
PCI Express x1	2
PCI Slots	3
SATA 3Gb/s	5
SATA 6Gb/s	1
Audio	Realtek ALC892
USB 3.0	2 x Rear, 2 x Header
LAN	Realtek 8111E
Video Outputs	VGA, DVI, HDMI
Memory Slots	4 x DIMM
