MSI G41TM-S01 Series User Manual

2-10
Hardware Setup ▍
MS-7602
Hardware Setup ▍
MS-7602
back paneL
Mouse/Keyboard
The standard PS/2
®
mouse/keyboard DIN connector s for a PS/2
®
mouse/keyboard.
VGA Port
The DB15-pn female connector s provded for montor.
DVI-D Port
The DVI-D (Dgtal Vsual Interface-Dgtal) connector allows you to connect a LCD
montor. It provdes a hgh-speed dgtal nterconnecton between the computer and ts
dsplay devce. To connect an LCD montor, smply plug your montor cable nto the DVI
-D connector, and make sure that the other end of the cable s properly connected to
your montor (refer to your montor manual for more nformaton.)
LAN
The standard RJ-45 LAN jack s for connecton to
the Local Area Network (LAN). You can connect a
network cable to t.
LED Color LED State Condton
Left Yellow O󰘯 LAN lnk s establshed.
On(Steady state) LAN lnk s establshed.
On(brghter & pulsng) The computer s communcatng wth another computer on the LAN.
Rght
Green O󰘯 10 Mbts/sec data rate s selected.
On 100 Mbts/sec data rate s selected.
Orange On 1000 Mbts/sec data rate s selected.
USB Ports
The USB (Unversal Seral Bus) port s for attachng USB devces such as keyboard,
mouse, or other USB-compatble devces.
▶
▶
▶
▶
▶
Mouse
DVI-D Port
LAN
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-OutUSB Ports
Yellow Green/ Orange
Keyboard
VGA Port
