Safety Information
Specifications
Specifications
CPU
Supports 6th/ 7th Gen Intel
®
Core
™
i3/i5/i7 processors, and
Intel
®
Pentium
®
and Celeron
®
processors for Socket LGA1151
Chipset Intel
®
H270/ B250 Chipset
Memory
y
4x DDR4 memory slots, support up to 64GB

7th Gen processors support DDR4 2400/ 2133 MHz*

6th Gen processors support DDR4 2133 MHz*
y
Dual channel memory architecture
y
Supports Intel
®
Extreme Memory Profile (XMP)**
** DDR4 memory modules can only run at maximum of 2400
MHz for 7th Gen processors and 2133 MHz for 6th Gen
processors on XMP mode.
Expansion Slots
y 1x PCIe 3.0 x16 slot (supports x16 mode)
y 2x PCIe 3.0 x1 slots
Onboard Graphics
y 1x HDMI
™
port, supports a maximum resolution of
4096x2160@24Hz, 2560x1600@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz
y 1x VGA port, supports a maximum resolution of
2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
Storage
Intel
®
H270/ B250 Chipset
y 6x SATA 6Gb/s ports
y 1x M.2 slot (Key M)
 Supports up to PCIe 3.0 x4 and SATA 6Gb/s
 Supports 2242/ 2260 /2280 storage devices
 Intel
®
Optane™ Memory Ready
y H270 supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA
storage devices
USB
Intel
®
H270/ B250 Chipset
y 6x USB 3.1 Gen1 (SuperSpeed USB) ports (3 Type-A & 1
Type-C ports on the back panel, 2 ports available through the
internal USB connector)
y 6x USB 2.0 (High-speed USB) ports (2 ports on the back
panel, 4 ports available through the internal USB connector)
Audio
y Realtek
®
ALC887 Codec
y 7.1-Channel High Definition Audio
LAN 1x Realtek
®
8111H Gigabit LAN controller
Continued on next page

MSI H270M PRO-VDH Specifications

General

Brand	MSI
Model	H270M PRO-VDH
Category	Motherboard
Language	English
