MSI H310M PRO-VH User Manual

4
Specifications
Continued from previous page
Back Panel
Connectors
y 1x PS/2 keyboard/Mouse combo port
y 4x USB 2.0 ports
y 1x DVI-D port (H310M PRO-VD/ H310M PRO-D)
y 1x VGA port (H310M PRO-VH/ H310M PRO-VD/ H310M
NANO/ H310M WIND/ H310M FIRE)
y 1x HDMI™ port (H310M PRO-VH/ H310M FIRE)
y 2x USB 3.1 Gen1 Type-A ports
y 1x LAN (RJ45) port
y 3x audio jacks
Internal
Connectors
y 1x 24-pin ATX main power connector
y 1x 8-pin ATX 12V power connector
y 4x SATA 6Gb/s connectors
y 1x USB 3.1 Gen1 connector (supports additional 2 USB 3.1
Gen1 ports)
y 1x USB 2.0 connector (supports additional 2 USB 2.0 ports)
y 1x 4-pin CPU fan connector
y 1x 4-pin system fan connector
y 2x Front panel connectors
y 1x Front panel audio connector
y 1x Serial port connector
y 1x TPM module connector
y 1x Chassis Intrusion connector
y 1x Clear CMOS jumper
y 4x EZ Debug LED
I/O Controller NUVOTON NCT5567 Controller Chip
Hardware
Monitor
y CPU/System temperature detection
y CPU/System fan speed detection
y CPU/System fan speed control
Form Factor
y m-ATX Form Factor
y 8.9 in. x 7.3 in. (22.6 cm x 18.5 cm)
BIOS Features
y 1x 128 Mb flash
y UEFI AMI BIOS
y ACPI 6.1, SM BIOS 2.8
y Multi-language
Continued on next page

MSI H310M PRO-VH Specifications

General

Form Factor	Micro-ATX
Chipset	Intel H310
CPU Socket	LGA 1151
Maximum Memory	32 GB
Expansion Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
Storage Interfaces	4 x SATA 6Gb/s
LAN	Realtek 8111H Gigabit LAN
Memory Slots	2 x DIMM
Memory Speed	2666/ 2400/ 2133 MHz
USB Ports	4 x USB 3.1 Gen1
Graphics Output	1 x VGA, 1 x HDMI
Audio	Realtek ALC887
M.2 Slots	1 x M.2 (Key M)
