MSI Modern 14 User Manual

2-14 2-15
Introductions
Keyboard Backlight LED Settings (optional)
Press repeatedly to select a backlight LED level according to
your preference.
LCD Settings
• f9: Decrease the LCD brightness.
• f10: Increase the LCD brightness.
Switch Display
Switch the display output mode between the LCD, external
monitor and both.
Screen Rotation
Rotate the screen upside down for 180 degrees. Press again to
rotate the screen back to its default position.
Screen Capture
+
It is a must to use FN and prtscr keys to take a screen capture
to the clipboard, and then be pasted into an editing program.
Use Multiple Monitors
+
If users connect an additional monitor to the notebook, the
system will automatically detect the external monitor connected.
Users will be allowed to customize the display settings.
• Connect the monitor to the notebook.
• Press and hold the Windows key, and then press [P] key to
bring up [Project].
• Select how you want your display to project on the second
screen from the selections of PC screen only, Duplicate,
Extend, and Second screen only.
Downloaded from ManualsNet.com search engine

MSI Modern 14 Specifications

General

Color name	Onyx Black
Form factor	Clamshell
Product type	Laptop
Product color	Black
Color gamut	45 %
Touchscreen	-
LED backlight	Yes
RGB color space	NTSC
Display diagonal	14 \
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i3-10110U
System bus rate	4 GT/s
Processor family	Intel® Core™ i3
Processor socket	BGA 1528
Processor threads	4
Processor codename	Comet Lake
Configurable TDP-up	25 W
Processor frequency	2.1 GHz
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x2, 1x2+2x1, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.6 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	16
Internal memory	4 GB
Memory clock speed	2666 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
SSD interface	NVMe
Storage media	SSD
Total storage capacity	128 GB
Compatible memory cards	SD, SDHC, SDXC
Discrete graphics card	No
Number of execution units	23
On-board graphics card ID	0x9B41
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Audio system	Nahimic 3D
Speaker power	2 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Front camera HD type	HD
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
AC adapter power	65 W
Pointing device	Touchpad
Keyboard backlit color	White
Keyboard number of keys	84
Battery capacity	50 Wh
Processor ARK ID	196451
Processor package size	46 x 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0

Weight and Dimensions

Depth	222 mm
Width	322 mm
Height	16 mm
Weight	1188 g
