2-12
MS-7320 Mainboard
Audio Ports
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.
SS-Out (Gray) - Side-Surround Out 7.1 channel mode.
RS-Out (Black) - Rear-Surround Out in 4/ 5.1/ 7.1 channel mode.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
CS-Out (Orange) - Center/ Subwoofer Out in 5.1/ 7.1 channel mode.
Mic/ Line-In (Pink) - Mic, is a connector for microphones. Line In, is used
for external CD player, tapeplayer or other audio
devices.
S/PDIF-Out (Optical)
This SPDIF (Sony & Philips Digital Interconnect Format) connector is provided for
digital audio transmission to external speakers through an optical fiber cable.
Important
Use only one of the three types of S/PDIF-out, optical S/PDIF-out, coaxial S/
PDIF-out, or onboard 2-pin S/PDIF-out connector for HDMI graphics card,
otherwise the audio transmission will be distorted.
