MSI Pulse GL66 User Manual

3-14 3-15
How to Get Started
Wired LAN
Using cables and network adapters to connect to the Internet. Before setting up the
connection of Dynamic IP/PPPoE or Broadband (PPPoE) or Static IP, contact your
Internet Service Provider (ISP) or network administrator for assistance of setting up
Internet connection.
▶ Dynamic IP/PPPoE Connection
1. Open up Settings, find and click [Network & Internet].
2. Select [Ethernet] within the Network & Internet selection menu.
3. Select [Change adapter options] to bring out Network Connections window.
4. Right click on [Ethernet] to select [Properties] from the drop-down menu.
5. Open up Ethernet Properties window, find and select [Internet Protocol
Version 4 (TCP/IPv4)] in Networking tab. Then click [Properties] to continue.
6. Click [Obtain an IP address automatically] and [Obtain DNS server address
automatically] in General tab. Then click [OK].
▶ Static IP Connection
7. Follow the previous steps 1 to 4 to continue.
8. Click [Use the following IP address] and [Use the following DNS server
addresses] in General tab. Fill the IP address, Subnet mask, Default gateway,
Preferred DNS server, and Alternate DNS server. Then click [OK].

MSI Pulse GL66 Specifications

General

Display diagonal	15.6 \
Processor cache	24 MB
Processor cores	8
Processor model	i7-11800H
Processor family	Intel® Core™ i7
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor boost frequency	4.6 GHz
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	3200 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express 3.0
Storage media	SSD
Total storage capacity	1000 GB
Number of SSDs installed	1
On-board graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 3060
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card memory	6 GB
Discrete graphics memory type	GDDR6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Battery capacity	53.5 Wh
Bluetooth version	5.1
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Front camera HD type	HD
Video capturing speed	30 fps
Audio system	Nahimic 3
Motherboard chipset	Intel HM570
Pointing device	Touchpad
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Market positioning	Gaming
AC adapter power	180 W

Weight and Dimensions

Depth	259 mm
Width	359 mm
Height	23.95 mm
Weight	2300 g
