2-17
Introductions
Left Side View
1. Power Connector
To connect the AC/DC adapter and supply power for the notebook.
2. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.
3. USB Port
The USB port allows you to connect USB-interface peripheral devices, such as the mouse,
keyboard, modem, portable hard disk module, printer and more.
4. VGA Port
The 15-pin D-sub VGA port allows you to connect an external monitor or other standard
VGA-compatible device (such as a projector) for a great view of the computer display.
1. Power Connector
2. Ventilator
3. USB Port
4. VGA Port
5. HDMI Connector
1 2 3
4 5
To Next Page
