Overview of Components

Important

For a single PCIe x16 expansion card installation with optimum performance, using

the PCI_E1 slot is recommended.

When adding or removing expansion cards, always turn off the power supply and

unplug the power supply power cable from the power outlet. Read the expansion

card’s documentation to check for any necessary additional hardware or software

changes.

Installing SLI graphics cards

For power supply recommendations for SLI configurations, please refer to the user

guide of your graphics card to make sure you meet all the system requirements.

To install SLI graphics cards:

1. Turn off your computer and disconnect the power cord, install two graphics cards

into the PCI_E1 and PCI_E4 slots.

2. Connect the two cards together using the SLI Bridge Connector.

3. Connect all PCIe power connectors of the graphics cards.

4. Reconnect the power cord, power up the computer and install the drivers and

software included in your graphics card package.

5. Right-click the Windows desktop and select NVIDIA Control Panel from the menu,

click on Configure SLI, Surround, PhysX in the left task pane and select Maximize

3D performance in the SLI configuration menu, and then click Apply.
