MSI Z270 SLI PLUS User Manual

39
Onboard LEDs
Onboard LEDs
EZ Debug LEDs
These LEDs indicate the status of key components during booting process. When an
error is occurred, the corresponding LED stays lit until the problem is solved.
CPU - indicates CPU is not detected or fail.
DRAM - indicates DRAM is not detected or fail.
VGA - indicates GPU is not detected or fail.
BOOT - indicates the booting device is not detected
or fail.

MSI Z270 SLI PLUS Specifications

General

Form Factor	ATX
Chipset	Intel Z270
CPU Socket	LGA 1151
Memory Slots	4 x DIMM
Max Memory	64 GB
PCIe Slots	3 x PCIe 3.0 x16, 3 x PCIe 3.0 x1
Storage Interface	6 x SATA 6Gb/s, 2 x M.2
LAN	Intel I219-V Gigabit LAN
RAID Support	RAID 0, 1, 5, 10
USB Ports	6 x USB 3.1 Gen1, 6 x USB 2.0
USB 3.1 Gen2 (Rear)	1 x USB 3.1 Gen2 Type-A, 1 x USB 3.1 Gen2 Type-C
Audio	Realtek ALC892
Multi-GPU Support	NVIDIA SLI, AMD CrossFire
Memory Speed	3800(OC)
