MSI Z270 SLI PLUS User Manual

78
Software Description
Speed Testing
The speed testing is used to optimize bandwidth usage. To test the Upload and Down-
load speed, please follow the steps below:
1
1. Click the Network Test block in NETWORK MANAGER.
2
3
4
2. Click Test Network Speed button. The test takes several minutes to test your
network speed.
3. Enter the testing results into Upload Speed and Download Speed fields.
4. Check the Enable Bandwidth Control to allow the NETWORK MANAGER to
manage the bandwidth.

MSI Z270 SLI PLUS Specifications

General

Form Factor	ATX
Chipset	Intel Z270
CPU Socket	LGA 1151
Memory Slots	4 x DIMM
Max Memory	64 GB
PCIe Slots	3 x PCIe 3.0 x16, 3 x PCIe 3.0 x1
Storage Interface	6 x SATA 6Gb/s, 2 x M.2
LAN	Intel I219-V Gigabit LAN
RAID Support	RAID 0, 1, 5, 10
USB Ports	6 x USB 3.1 Gen1, 6 x USB 2.0
USB 3.1 Gen2 (Rear)	1 x USB 3.1 Gen2 Type-A, 1 x USB 3.1 Gen2 Type-C
Audio	Realtek ALC892
Multi-GPU Support	NVIDIA SLI, AMD CrossFire
Memory Speed	3800(OC)
