Chapter 7 Related Documents
SCV-series Screw Compressor 7.6 Tools for Disassembly
7-31
7.6 Tools for Disassembly
Table 7-13 List of Tools for Disassembly (example)
Tool name Illustration size, etc.;
Parts Center
Code No.
Ratchet wrench 1/4” SG261-08
Adjustable wrench 250 mm SG231-250
Screwdriver Phillips
75 mm
SG112-075
125 mm SG112-125
Screwdriver Flat blade
75 mm
SG111-075
125 mm SG111-125
Snap ring pliers External
ST-1
SG311-01
ST-2N SG311-02N
ST-3
SG311-03
Snap ring pliers Internal
RT-4 SG312-04
RT-5 ―
Eye bolt
M8×200
two-peace-set
UHT0016
Allen wrench key
Across
flats
2 mm
SG241-02
3 mm
SG241-03
4 mm
SG241-04
5 mm
SG241-05
6 mm
SG241-06
8 mm
SG241-08
10 mm
SG241-10
12 mm
SG241-12
14 mm
SG241-14
17 mm
SG241-17
19 mm
SG241-19
Lock nut wrench
AN-05
SAS111-05
AN-07
SAS111-07
AN-08
SAS111-08
AN-10
SAS111-10
AN-12
SAS111-12
AN-13
SAS111-13
AN-17
SAS111-17
AN-21
SAS111-21
