Figure 1. Cable Connections for EMC Compliance
NI 9230
with Screw Terminal
Shield
AI0+
AI0–
Shield
AI1+
AI1–
Shield
AI2+
AI2–
Ferrite
Signal
Source
Signal
Source
Signal
Source
Ferrite
Ferrite
Special Conditions for Marine Applications
Some products are Lloyd’s Register (LR) Type Approved for
marine (shipboard) applications. To verify Lloyd’s Register
certification for a product, visit ni.com/certification and search
for the LR certificate, or look for the Lloyd’s Register mark on
the product.
10 | ni.com | NI 9230 Getting Started Guide
