National Instruments PXI-8360 User Manual

© National Instruments Corporation 3 Set Up Your MXI-Express x1 System
Table 1. MXI-Express x1 Connectivity Support From a Host PC Using a Copper Cable
From Host Targets
Slot Type Product
PXI Chassis VXI Chassis PXI Express Chassis MXI-Express RIO
NI PXI-8360 NI PXI-1033
*
NI VXI-8360T NI PXIe-8360 NI PXIe-1073
*
NI 9157
*
NI 9159
*
PCI NI PCI-8361  —
†
—
†
—
†
—
†
— —
PCI Express x1 NI PCIe-8361       
PCI Express x1 NI PCIe-8362       
ExpressCard NI ExpressCard-8360       
Industrial
Controller
NI 3100/3110
*
      
*
Product has an integrated MXI-Express x1 port.
†
These configurations are not supported, even though the front panel MXI connectors are mechanically compatible. For these configurations the boards will likely report a valid cable link via the
front panels LEDs. Since these link scenarios expose a possible data integrity issue that may not be obvious to the user, National Instruments strongly recommends against using these configurations.
Note: For installation instructions and other information concerning the NI PXI-1033, NI PXIe-1073, NI VXI-8360T, NI 9157, NI 9159, and the NI 3100/3110, refer to their respective user manuals.
Note: For full PXI or PXI Express functionality, refer to the Software Installation and Configuration section.
Note: PCI Express host slots will give better throughput and latency performance than PCI slots.
