Navico BSM-1 User Manual

Parts List | 19
EN
Part no
Description
000-0106-82
B260 Bronze Thru Hull 50/200Khz Depth/Temp
w 19/6
Block.
12 m (39.4 ft) cable
000-0106-91
M260 Plastic In-Hull 50/200Khz Depth Only
Tank Kit w 19/6° Beamwidths.
12 m (39.4 ft) cable
000-0106-77
XDCR ASY HST-DF SBL.
7 m (23 ft) cable
000-10116-001
TM260 Plastic Transom Mount 50/200Khz
Depth/Temp with 19/6° Beamwidths and
Kickup Bracket.
10 m (32.8 ft) cable
Optional parts
Part no
Description
AA010009
Navico 8 port Ethernet Linker (RJ45 type)
000-0132-031
Navico NEP-1 4 port Ethernet Linker (HDS
type - orange connector)
000-00022-001
Transducer adapter cable - 6 Pin LTW to 7 Pin
BLUE 0.6 m (2 ft)
000-10046-001
Transducer adapter cable, 7 Pin BLUE with free
ends 0.6 m (2 ft)
Spare parts for service
Part no
Description
151-10016-001
Module for BSM-1 box
Special Notes:
1. Cable 000-00022-001 potentially allows use of an
existing Airmar transducer already installed in your
boat. For NSE displays both depth and temp can be
used. Select your transducer with a 10K value in the
installation page of your NSE for proper reading. GB40
and 8000i will display improper temperature until your
transducer is changed to one listed on page 18 with a
5K value.
