14 Installing the Boiler
2.1 Removing the Wood Pallet from the
Boiler
After you open the box, remove the wood pallet and the pallet
brackets and then install the boiler.
CAUTION
After opening the box, verify that all included accessories are
present in the accessory box and upper container.
Removing the Wood Pallet and the Pallet Brackets
1. Remove the L and R boxes.
Note
Do not discard the L box, as it contains the wall-
mounting bracket and the anti-vibration rubber
pad.
2. Loosen the eight screws that secure the wood pallet on the
bottom left and right sides of the boiler.
3. Remove the wood pallet, the upper container, and the lower
pad.
Upper
Container
Lower Pad
Wood Pallet
4. Loosen the eight screws that secure the pallet brackets.
CAUTION
Keep the removed screws in a safe place. The screws will be
used again in Step 6.
2. Installing the Boiler
To Next Page
