Specifications
Display: 12.1-inch (30.7 cm viewable image size); active
matrix; thin film transistor (TFT); liquid crystal
display (LCD); 0.24 mm dot pitch; RGB vertical stripe
color filter arrangement; 200 cd/m² white luminance,
typical; 150:1 contrast ratio, typical
Compatibility: 720 x 400: VGA text
640 x 480: VGA, 60 Hz to 85 Hz vertical refresh
800 x 600: 56 Hz to 85 Hz vertical refresh
1024 x 768 non-interlaced: 60 Hz to 75 Hz vertical
refresh
Synchronization
Frequencies:
Horizontal: 24.8 kHz to 62.0 kHz
Vertical: 53.7 Hz to 85 Hz (up to 75 Hz
for l 024 x 768)
Pixel Frequency: 21.1 MHz to 78.8 MHz
H Sync Jitter: Less than 10% of pixel
frequency (recommended)
Resolution: Horizontal: 1024 dots
Vertical: 768 lines
Active Display Area: Horizontal: 245.8 mm
Vertical: 184.3 mm
Viewing Angles: Up 20°
Down 20°
Right 30°
Left 30°
E - 20 Specifications
