NEC AccuSync AS191WM User Manual

English
English-9
AUDIO
Controls the volume of the speakers or headphones.
To mute the speaker output, press the “12/RESET” button.
BRIGHTNESS
Adjusts the overall image and background screen brightness.
To enter the ECO MODE, press the “12/RESET” button.
ECO MODE OFF: Set brightness variable from 0% to 100%.
ECO MODE1:
AS191WM: Set brightness 80%.
AS221WM: Set brightness 70%.
This setting can adjust brightness within the range that power has reduced meeting Energy Star measurement
condition.
ECO MODE2:
AS191WM: Set brightness 30%.
AS221WM: Set brightness 20%.
This setting can adjust brightness within the range that power has reduced 30% from maximum brightness setting.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO CONTRAST
Adjusts the image displayed for non-standard video inputs.
AUTO ADJUST
Automatically adjusts the Image Position, the H. Size and Fine setting.
LEFT/RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN/UP
Controls Vertical Image Position within the display area of the LCD.
H. SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
Improves focus, clarity and image stability by increasing or decreasing this setting.
COLOUR CONTROL SYSTEMS
Five colour presets (9300/7500/sRGB/USER/NATIVE) select the desired colour setting.
COLOUR RED
Increase or decreases Red. The change will appear on screen.
COLOUR GREEN
Increase or decreases Green. The change will appear on screen.
COLOUR BLUE
Increase or decreases Blue. The change will appear on screen.
TOOL
Selecting TOOL allows you to get into the sub menu.
FACTORY PRESET
Selecting Factory Preset allows you to reset all OSD control settings back to the factory settings. The RESET button
will need to be held down for several seconds to take effect. Individual settings can be reset by highlighting the
control to be reset and pressing the RESET button.

NEC AccuSync AS191WM Specifications

General

Pixel pitch	0.28 x 0.28 mm
Aspect ratio	16:10
Display diagonal	19 \
Separate H/V sync	Yes
Display resolution	1440 x 900 pixels
Video input impedance	75 Ω
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	176 °
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 81.1 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1152 x 870, 1280 x 960, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
DVI-I ports quantity	0
Certification	Energy Star 5.0 TCO 5.0 EPEAT Silver
Product color	Black
Compliance industry standards	RoHS
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (typical)	21 W
Power consumption (PowerSave)	0.4 W
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	209.8 mm
Height (with stand)	347.1 mm
Weight (with stand)	4400 g
Depth (without stand)	64.6 mm
Width (without stand)	439.4 mm
Height (without stand)	299.8 mm
Weight (without stand)	4100 g
