DSX Basic Online Training Quick Reference Hardware Installation ◆ 5
Door Boxes
Cabling
Optional Equipment
Data Connections
Data Connections
For more on these topics Turn here
Connecting Door Boxes DSX-80/160 Hardware Manual 1093096 Rev 2 Page 58
Door Box feature DSX Software Manual 1093100 Rev 3 Page 147
Door Box programming DSX Software Manual 1093100 Rev 3 Page 148
Important
• Connect a 2PGDAD Module to a 16ESIU station port, then
connect up to two analog Door Boxes to the 2PGDAD Module.
For more on these topics Turn here
16ESIU PCB cabling DSX-80/160 Hardware Manual 1093096 Rev 2 Page 32
SLIU PCB cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 34
COIU PCB cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 36
Extension cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 41
Important
• For your convenience, use pre-made cable P/N 80892.
For more on these topics Turn here
Connecting External Paging DSX-80/160 Hardware Manual 1093096 Rev 2 Page 61
Connecting music sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 62
Important
• The DSX CPU PCB provides music inputs and outputs.
For more on these topics Turn here
Connecting PC Programming and
SMDR
DSX-80/160 Hardware Manual 1093096 Rev 2 Page 70
Important
• PC Programming is not available via the CPU PCB serial port.
For more on these topics Turn here
Installing IntraMail DSX-80/160 Hardware Manual 1093096 Rev 2 Page 57
Important
• The IntraMail CompactFlash card plugs into the CPU PCB.
