NEC MultiSync E171M User Manual

English-8
Controls
OSD (On-Screen Display) control buttons on the front of the monitor
function as follows:
1. Basic function at pressing each key:
Button
SELECT
–
+
1!2/RESET
Not displaying on screen
Displays OSD. Shortcut to Brightness. Shortcut to Volume. Selects input signal.
Displaying on screen
Icon Select
Displays OSD menu and
selects function icon.
Moves leftward. Moves rightward.
Displaying on screen
Function Adjustment
Adjusts the function of the
selected icon.
Adjusts down. Adjusts up. Resets the function.
Mutes off/on switch on.
2. OSD structure
Main Menu (Icon Select)
Sub Menu (Icon Select)
Press
“SELECT”
key
Press
“SELECT”
key
Press
“–” or “+”
Main Menu (Adjust)
Sub Menu (Adjust)
Press “SELECT” key
Press
“SELECT” key
Adjust by using
“–” or “+”
Adjust by using
“–” or “+”
Press
“–” or “+”
Example Tool:
Press “SELECT” key
Press
“SELECT” key
