Rails en
33
pRails
Rails
With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
shelves and clean them.
Changing the shelf position for the
telescopic rail
Bars and telescopic rails can be positioned in any
order. For example, you can fit the telescopic rail to the
shelf position which you use the most frequently.
Removing the bar
Telescopic rails are removed and fitted like bars.
1. Push the bar towards the back ‚ until it can be
pulled out upwards ƒ (Fig. !).
2. Unhook the bar at the back and remove it (Fig. ").
Fitting the bar
1. Fit the bar at the back (Fig. !).
2. Push the bar towards the back ‚ and down ƒ onto
the pin „ (Fig. ").
3. Ensure that the hook is hooked onto the pin „ (Fig.
#).
Detaching and refitting the rails
:Warning – Risk of burns!
The rails become very hot. Never touch the hot rails.
Always allow the appliance to cool down. Keep children
away from the appliance.
Detaching the rails
1. Lift the rail slightly at the front ‚ and detach it ƒ (do
not hold by the accessory holders or the telescopic
shelf) (figure !).
2. Then pull the whole rail towards you and take it out
(figure ").
Clean the rails with cleaning agent and a sponge. For
stubborn deposits of dirt, use a brush.
Attaching the rails
The rails only fit on the right or the left side. The pull-out
rails must pull out towards you.
1. First, insert the rail in the middle of the rear socket ‚,
until the rail rests against the cooking compartment
wall, and push it back ƒ (figure !).
2. Then insert the rail into the front socket „, until the
rail also rests against the cooking compartment wall
here, and press it downwards … (figure ").
2
1
E
1
F
2
F
E
2
D
E
1
F
G
2
D
E
1
