Hardware Features
Before you install and connect your router, take a moment to become familiar with the front and
back panels of the router—especially the status lights on the front panel.
Front Panel
The router front panel, shown in Figure 3, contains status lights. (For more information on
interpreting the status lights, see “Verifying Your Connection” on page 16 and “Checking Basic
Router Functions” on page 27.)
You can use the status lights to verify various conditions.
Figure 3
Table 1. Status Light Descriptions
Label Activity Description
1. Power
Solid Amber
Solid Green
Off
The router is performing the power-on self-test diagnostic.
The power is on and the router is ready.
Power is not being supplied to the router.
1
2
3
4
5
