Parts List - NEUTON CE6.2 Mower
NOTE: Part numbers listed are available through Neuton Power Equipment
Item # Description Qty Part # Item # Description Qty Part #
1 Spring, Battery Pack Cover
(small)
1 240821 19 Base, Fixed, Trimmer Arm
Support Cap
1 238371
2 Cover, Battery Pack 1 238401 20 Label, Height Adjustment 1 237491
3 Spring, Extension of Spring
for Battery Pack Cover
2 238411 21 Label, Optimize Performance 1 237531
4 Pin, Battery Pack Cover (POM) 2 238421 22 Label, Battery Alignment 1 196021
5 Screw, 4mm x 16mm 10 196371 23 Base, Fixed, Push Button 1 238331
6 Wrench, 16mm 1 240841 24 Spring, 19mm, Length 1 238351
7 Wrench, 36mm 1 176281 25 Button, Push 1 238341
8 Screw, 5mm x 20mm,
Housing
4 240131 26 Motor 1 238581
9 Arm, Battery 1 196441 27 Screw w/Washer, Contact 2 176111
10 Strap, Safety Key (orange) 1 206511 28 Wire, Red, #12, 250mm L,
Battery
1 240911
11 Key, Safety 1 175931 29 Screw, 4mm x 16mm 6 243701
12 Label (Operating Instructions) 1 237381 30 Wire, Black, #16, 460mm L,
Trimmer
1 240921
13 Label (Safety Key) 1 237501 31 Wire, Red, #16, 470mm L,
Trimmer
1 240931
14 Label (Neuton Badge) 1 210531 32-34 Circuit Board and Relay Assy 1 238621
15 Housing, Upper 1 238321 32 Relay, Trimmer 1
16 Pin, Spring 1 238381 33 Relay, Mower 1
17 Spring, 18.5mm, Length 1 238391 34 Circuit Board 1
18 Cap, Trimmer Arm Support 1 238361 35 Wire, Black, #12, 380mm L,
Battery
1 240901
