SECTION 00 -- GENERAL 31
604.13.542.01 -- 03 -- 2006
HYDRAULIC SYSTEM
Gear pump Hydraulic and steering system
Hydraulic system pressure:
Main system pressure 250 bar
Steering system pressure 175 bar
TORQUES Nm
Wheel nuts 540
Cab securing screws 380
RADIATOR COOLANT
The antifreeze must be changed every 1000 hours or every 24 months
NOTE: To reduce deposits and limit corrosion, thewaterused in thecoolingsystemmust not exceed thefollow-
ing limits:
Total hardness Chloride Sulphates
300 ppm 100 ppm 100 ppm
TYRE COMBINATION FOR 4--WHEEL DRIVE VEHICLES
The tyres mounted on 4--wheel drive machines are selected so that they are compatible with the transmission
and axle gears. Whendamagedor worn tyres are replaced, always mount tyres of brand,model and dimension
equal to the previous ones. The installation of combined tyres can result in an excessive wear, loss of available
power or serious damage to the transmission components. If in doubt, consult your Dealer.
MACHINE WEIGHT
Weight
13 metre= 10,480 kg
14 metre= 10,780 kg
17 metre= 11,760 kg
TH100028
5
IMPOR TANT: The data listed hereabove and below
are general data provided as a guide to evaluatethe
weight of the machine and do not necessarily con-
siderthetyresinstalled,thelevelof fluidsor thepres-
ence of additional equipment. To establish precisely
the weight of your machine, it is necessary to place
it on an official weight bridge.
