Contact with VVM 500
Exter nal information
When the indoor module door is closed, information can be received via an
information window and a status lamp.
,QIRUPDWLRQ ZLQGRZ
6WDWXV ODPS
Information window
The information window shows part of the display that is on the display unit
(located behind the door to the indoor module). The information window
can display different types of information, e.g. temperatures, clock, etc.
You determine what is to be displayed in the information window. Your own
combination of information is entered using the display unit. This information
is specific to the information window and disappears when the front hatch
of the indoor module door is opened.
Instructions on how to set the information window can be found on page
50.
Status lamp
The status lamp indicates the status of the indoor module: continuous green
light during normal function, continuous yellow light during activated emer-
gency mode or continuous red light in the event of a deployed alarm.
Alarm management is described on page 57.
11NIBE™ VVM 500Chapter 2 | The heating installation – the heart of the house
