English – 12
EN
Technical specifications of product
Oview is produced by Nice S.p.a. (TV) I.
Type: control, programming and diagnostics unit for devices equipped with
BusT4 connector
Technology adopted: half duplex 19200 Bps serial connection on differen-
tial bus for delivery of commands, modification or parameters and monitor-
ing of diagnostic data
Graphic interface: LCD display 128 x 64 dots (46 x 29 mm); 2,2”
Operator input device: joypad con 5 + 2 keys
Display/key lighting: white light
(colour coordinates: X = 0,29–0,33; Y = 0,30–0,34)
Calendar/clock: internal, with backup battery (minimum lifetime 10 years)
Maximum number of hourly commands: 64
Event log: storage capacity of 400 events
Connection cable length:
– cable supplied: 2 m
– other cable: up to 700 m, measured from point to point
Power supply: supplied by devices present on BusT4
Absorbed current: Maximum 20 mA (without accessories)
Insulation: Class III
Casing protection rating: IP 20
(use indoors or in protected environments only)
Operating temperature: from –20°C to +55°C
Dimensions (mm): 107 x 61 x h 20
(with wall-mounting support: 125 x 70 x h 32)
Weight: 75 g (without cable)
Optional accessories:
• module for connection via Bluetooth
®
technology
• module for connection via GSM
®
–GPRS
®
technology
