Nikon MONARCH Series User Manual

193
Pb
Giro do cano da lente (somente modelos angulados)
Se afrouxar o fixador girando-o no sentido anti-horário, você poderá girar o cano da lente.
0˚
180˚
90˚
90˚
45˚
45˚
135˚
135˚
Fixador
• O cano da lente emite um clique a cada incremento de 45 graus.
• Aparafuse o fixador para travar o cano da lente em qualquer ângulo.

Nikon MONARCH Series Specifications

General

Series	MONARCH
Waterproof	Yes
Fogproof	Yes
Magnification	8x, 10x, 12x
Objective Lens Diameter	30mm, 42mm, 56mm
Prism System	Roof
Field of View	Varies by model
Eye Relief	Varies by model
Close Focus Distance	Varies by model
Weight	Varies by model
Dimensions	Varies by model
Color	Black
